Hand Pump Assembly
With nearly three decades of experience into handpump manufacturing and maintaining high quality engineered supplies in the Indian domestic market, we strive to serve the Internal export market of Africa & Asia with all your requirements as to:
Hot-dip galvanised-
- IM-II standard deep well hand-pump SDWP - India MKII
- India MKIII Deepwell Handpump
- Extra Deepwell (ED) Hand Pump
- Afridev Hand Pumps
- Ghana modified India MKII
- U2 Shallow Well Uganda 2 Head and Handle Assembly
We can cater to your customized needs as to medium or heavy weight full size hand pump assembly as per standards with mild-steel connecting rods or stainless-steel SS connecting rod where the quality of water is hard and corrosive.
Similarly; cylinder body and its components are available in cast-iron CI cylinder with Gun Metal components and SS cylinder with SS components.
Hand Pump Set, Standard Deep Well Pump (SDWP) - INDIA MARK II Type:
Head Assembly comprising of galvanized-iron GI head welded, 32mm handle assembly , MS chain with coupling, SS handle axle, front cover, third plate, nuts & bolts
3-legged MS angle pedestal stand and water tank -32mm BSP MS socket.
With versions as per order available as to telescopic stand, extension piece – square pedestal.
Mark 3 - INDIA MARK III HandPumpType:
Been an improved & modified version of MKII – India MKIII has much parts in common with difference as to the cylinder body length and different lower and upper cap, pedestal stand length 615mm or 690mm plus the water tank has 65mm socket to accommodate the 65mm NB riser pipes
Afridev Hand Pump
A more durable and reliable version of hand pump – Afridev is much popular and known for its low maintenance and its unique features.
Customization as to varying length of spout, pedestal stand with options for threaded connecting rod, eye & hook connecting rods available both is mild steel and SS 202 and SS 304 grade
ED - Extra Deepwell Hand Pump
As the name suggests; extra deep well hand pump extract water from plus 50 meters depth as compared to other India MKII handpump models.
Size of head assembly bracket is broader to accommodate the 40mm square handle with a different cylinder assembly – available both in CI & Gun Metal as well complete SS cylinder assembly in SS 304
